Project Type: Co-op (Optikos)
Duration: November 2021
Skills Used: SolidWorks, 3D printing
Description: New iteration of 3D printed controller board mount. Now only one PCB, task for this was adjustable mounting in a more secure location. Flat ¼-20 screws secure the base to a dove tail mount, which is mounted on the test fixture. Base has two channels with clearance for jam nuts to secure controller PCB mounting plate. Rib runs through bottom center of mounting plate and interacts with channel in center of base to keep mounting plate from rotating through movement.
Additional Images:
